10.1 Inch Windows10 Rugged Tablet
Performance
Q10w Rugged Tablet PC supports Windows 10 system（optional Android 10）, a smoother user experience and stronger application compatibility.
Special modules such as ID card, fingerprint, UHF can be selected, and the application industry is more extensive.
It has an IP65 protection level and MIL-STD-810G Certification is as solid as a rock.
Support aviation plug to meet the requirements of industrial electricity.
Specification Parameter
| Basic parameters | |
| Dimension | 280.4 x 187 x 26.6mm |
| Weight | device unit 1014g |
| Device Color | black |
| LCD | 10.1 inch IPS 16:10, 800x1280/1200x1920 |
| Touch Panel | 10 point G+G capacitive touch screenCorning ® Gorilla ® Glass |
| Camera | Front 2.0MP Rear 5.0MP |
| I/O | HDMI 1.4a x 1,USB 2.0 Type-A x 1, Micro USB x 1,SIM Card x 1, TF Card x 1,12pins Pogo Pin x 1, DB9 RS232 x 1, RJ45 x 1, Φ3.5mm standard earphone jack x 1, Φ3.5mm DC jack x 1 |
| Power | AC100V ~ 240V, 50Hz/60Hz, Output DC 5V/3A |
| Communication | |
| WIFI | WiFi 802.11 a/b/g/n/ac (2.4G+5.8G) |
| Bluetooth | BT4.2 |
| 3G/4G(Optional) | LTE FDD: B1/B3/B5/B7/B8/B20/B28ALTE TDD: B38/B40/B41 WCDMA: B1/B2/B5/B8 GSM: B2/B3/B5/B8 |
| GNSS | Built-in GPS |
| Performance parameter | |
| CPU | Intel Atom x5 Z8350 |
| OS | Windows 10 |
| RAM | 4GB |
| ROM | 64GB/128GB |
| Battery | |
| Capacity | 3.7V/8000mAh |
| Type | Li_polyment, removeable battery |
| Endurance | 10hrs(default 50% volumn，default 200 nit， play 1080P HD video) |
| Data Collection | |
| NFC | Optional, 13.56MHz, ISO/IEC 14443A/B,ISO/IEC 15693, ISO/IEC 18092 |
| 1D | Optional, MOTO SE655E100R |
| 2D | Optional, EM80 |
| Fingerprint | Optional, FPC1020 |
| Reliability | |
| Operate Temperature | -20 °C ~ 60 °C |
| Store Temperature | -30 °C ~ 70 °C |
| Humidity | 95% Non-Condensing |
| Rugged Feature | IP65 certified, MIL-STD-810G certified |
| Drop Height | 1.22m |
Accessories（Optional）
Docking Charger
Hand-strap
Shoulder-strap
Back-strap
Leather Cover
Stylus
Vehicle Mount
Application Range
Various modules and accessories can be selected to meet customers' application in various industries.
Equipment Testing
Industrial Automation
Vehicle
Medical Treatment
